1P NO 10A push general symbol grey - 16080

Pdf
Vimar - 16080 - 1P NO 10A push general symbol grey
Vimar - 16080 - 1P NO 10A push general symbol grey

16080
Wiring devices / Traditional wiring devices / IDEA / Devices

1P NO 10A push general symbol grey
1P NO 10 A 250 V~ push button, general symbol, grey

Product Status
3 - Active

Drawings

view encumbered art. 16080
PNG DXF
rear view art. 16080
PNG DXF
3D view art. 16080
PNG DXF
Class group
Domestic switching devices
Class
Push button
Assembly arrangement
Modular device for domestic switching devices
Model
Single push button
Method of operation
Push button
Number of rockers
1
Number of modules (module system)
100
Number of poles
1
Nominal voltage
250 V
Rated current
10,00 A
With lighting
No
Feedback-signal contact
No
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7015
Transparent
No
Label space/information surface
Yes
Suitable for degree of protection (IP)
IP40
Device width
24,80 mm
Device height
50,10 mm
Device depth
36,10 mm

00. CE Marking - EU

01. IMQ - Italy

14. TSE - Turkey

15. CCC - China

19. NOM - Mexico

20. IQC - Argentina

28. NSW - Australia

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 50 NR

Barcode

Barcode Qty 1 NR
8007352002838
1 NR
4.1x2.8x5.3 [cm]
24.6 [g]
Barcode Qty 50 NR
8007352000070
50 NR
21.4x11.6x14.2 [cm]
1,325 [g]
Barcode Qty 500 NR
8007352263185
500 NR
57.5x22.5x30 [cm]
13,710 [g]
