2P 16AX 1-way switch luminous grey - 16036

Pdf
Vimar - 16036 - 2P 16AX 1-way switch luminous grey
Vimar - 16036 - 2P 16AX 1-way switch luminous grey

16036
Wiring devices / Traditional wiring devices / IDEA / Devices

2P 16AX 1-way switch luminous grey
2P 16 AX 250 V~ 1-way switch, luminous, for signalling unit. Provided without signalling unit. Max 200 W for self-ballasted lamps (IEC 60669-1:2017)

Product Status
3 - Active

Drawings

view encumbered art. 16036
PNG DXF
rear view art. 16036
PNG DXF
3D view art. 16036
PNG DXF
Class group
Domestic switching devices
Class
Installation switch
Wiring system
2-pole switch
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7015
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 V
Rated current
16,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
Yes
Device width
24,80 mm
Device height
50,10 mm
Device depth
36,10 mm
Built-in depth
23,00 mm

00. CE Marking - EU

14. TSE - Turkey

15. CCC - China

19. NOM - Mexico

20. IQC - Argentina

28. NSW - Australia

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352078284
1 NR
5.1x2.8x5.3 [cm]
35.6 [g]
Barcode Qty 20 NR
8007352078291
20 NR
27x11.6x6 [cm]
782.6 [g]
Barcode Qty 120 NR
8007352651357
120 NR
37.5x30x13.5 [cm]
5,052 [g]
