1P 16AX 2-way switch luminescent white - 16005.F.B

Pdf
Vimar - 16005.F.B - 1P 16AX 2-way switch luminescent white
Vimar - 16005.F.B - 1P 16AX 2-way switch luminescent white

16005.F.B
Wiring devices / Traditional wiring devices / IDEA / Devices

1P 16AX 2-way switch luminescent white
1P 16 AX 250 V~ 2-way switch, with luminescent indicator, white

Product Status
2 - Will be discontinued

Drawings

view encumbered art. 16005.F.B
PNG DXF
3D view art. 16005.F.B
PNG DXF
Class group
Domestic switching devices
Class
Installation switch
Wiring system
Two-way switch
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
White
RAL-number (similar)
9001
Label space/information surface
Yes
Illumination
No
Function lighting
Other
Type of lighting
Other
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 V
Rated current
16,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
Device width
24,80 mm
Device height
50,10 mm
Device depth
36,50 mm
Built-in depth
23,30 mm

00. CE Marking - EU

01. IMQ - Italy

14. TSE - Turkey

15. CCC - China

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352064942
1 NR
4.1x2.8x5.3 [cm]
29.87 [g]
Barcode Qty 20 NR
8007352064997
20 NR
21.4x11.6x6 [cm]
656.8 [g]
