Table mounting box 7M Silver - 14787.SL

Pdf
Vimar - 14787.SL - Table mounting box 7M Silver
Vimar - 14787.SL - Table mounting box 7M Silver

14787.SL
System infrastructure / Enclosures and control units / Connector block boxes / Desktop

Table mounting box 7M Silver
7-module table mounting box, Silver. To complete with mounting frame and cover plate

Product Status
2 - Will be discontinued

Drawings

view encumbered art. 14787.SL
PNG DXF
rear view art. 14787.SL
PNG DXF
3D view art. 14787.SL
PNG DXF
Class group
Domestic switching devices
Class
Surface mounted box for flush-mounted switching equipment
Assembly arrangement
Other
Suitable for modular domestic switching devices
Yes
Number of modules (module system)
7
Number of units
7
Mounting direction
Horizontal
Material
Plastic
Material quality
Other
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Matt
Colour
Silver
RAL-number (similar)
9006
Transparent
No
With cover frame
No
With duct entry
No
With cable entry
Yes
With screw gland entry
No
Shock resistant
Yes
Degree of protection (IP)
IP20
Device width
206,00 mm
Device height
80,00 mm
Device depth
67,60 mm

96. Electrotechnical expert

Minimum order quantity: 2 NR

Barcode

Barcode Qty 1 NR
8007352319110
1 NR
20.6x8x6.8 [cm]
185.27 [g]
Barcode Qty 2 NR
8007352319127
2 NR
24.4x13.9x10.1 [cm]
456.53 [g]
