Frame 3M +screws - 14613

14613
Wiring devices / Traditional wiring devices / PLANA / Mounting frames

Frame 3M +screws
3-module mounting frame, with screws, for 3-module mounting boxes

Product Status
3 - Active

You may also be interested in

21613.C - Cover 3M Eikon/Arké/Plana mount-frame

07937 - Screw for frame fixing - 35mm

07939 - Screw for frame fixing - 50 mm

• Documents and downloads
• ETIM technical data
• Certifications
• Supply data

Drawings

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Holder for modular domestic switching devices

Model
Flush-mounted

Mounting method
Mounting with screw

Mounting method of the module inserts
Front side

Mounting direction
Horizontal and vertical

Number of modules horizontal (module system)
3

Number of modules vertical (module system)
1

With built-in installation box
No

With screws
Yes

Suitable for mounting in round junction box 60 mm
No

Flush-mounted installation
Yes

Suitable for subfloor installation duct box
No

Suitable for wall duct
No

Suitable for mounting on DIN-rail 35 mm
No

Material
Plastic

Material quality
Thermoplastic

00. CE Marking - EU

01. IMQ - Italy

29. QCERT - Colombia

50. Product Environm. Profile

96. Electrotechnical expert

Minimum order quantity: 200 NR

---

Barcode

8007352108219

1 NR

11.8x7.4x2.2 [cm]

21.7 [g]

8007352147263

10 NR

11.8x7.46x15.2 [cm]

220.6 [g]

8007352147270

200 NR

38x34x24 [cm]

4,856 [g]

8007352263413

6,400 NR

80x120x127 [cm]

175,000 [g]
