Frame 2M wihtout screws 57mm - 14605

Pdf

14605
Wiring devices / Traditional wiring devices / PLANA / Mounting frames

Frame 2M wihtout screws 57mm
2-module mounting frame, without screws, for 60 mm fixing centres mounting boxes, modular, 57 mm distance between centres, for horizontal or vertical installation

Product Status
3 - Active

Drawings

Class group
Domestic switching devices
Class
Holder for modular domestic switching devices
Model
Flush-mounted
Mounting method
Mounting with screw
Mounting method of the module inserts
Front side
Mounting direction
Horizontal and vertical
Number of modules horizontal (module system)
2
Number of modules vertical (module system)
1
With built-in installation box
No
With screws
No
Suitable for mounting in round junction box 60 mm
No
Flush-mounted installation
Yes
Suitable for subfloor installation duct box
No
Suitable for wall duct
No
Suitable for mounting on DIN-rail 35 mm
No
Material
Plastic
Material quality
Thermoplastic

00. CE Marking - EU

29. QCERT - Colombia

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352118997
1 NR
6.02x7.08x1.52 [cm]
11.2 [g]
Barcode Qty 20 NR
8007352119000
20 NR
19x14.3x9.5 [cm]
299.2 [g]
