Frame 2M +claws 57mm - 14604

14604
Wiring devices / Traditional wiring devices / PLANA / Mounting frames

Frame 2M +claws 57mm
2-module mounting frame, with claws, for ø 60 mm mounting boxes, modular, 57 mm distance between centres

Product Status
3 - Active

• Documents and downloads
• ETIM technical data
• Certifications
• Supply data

Drawings

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Holder for modular domestic switching devices

Model
Flush-mounted

Mounting method
Mounting with claw

Mounting method of the module inserts
Front side

Mounting direction
Horizontal and vertical

Number of modules horizontal (module system)
2

Number of modules vertical (module system)
1

With built-in installation box
No

With screws
No

Suitable for mounting in round junction box 60 mm
Yes

Flush-mounted installation
Yes

Suitable for subfloor installation duct box
No

Suitable for wall duct
No

Suitable for mounting on DIN-rail 35 mm
No

Material
Plastic

Material quality
Thermoplastic

00. CE Marking - EU

01. IMQ - Italy

29. QCERT - Colombia

96. Electrotechnical expert

Minimum order quantity: 20 NR

---

Barcode

8007352118973

1 NR

7.16x6.06x2.5 [cm]

18.13 [g]

8007352118980

20 NR

24.4x13.9x8.4 [cm]

441.87 [g]

8007352642355

200 NR

47.5x27x29 [cm]

4,920 [g]

Share

Legal

Vimar reserves the right to change at any time and without notice the characteristics of the products reported. Installation should be carried out by qualified staff in compliance with the current regulations regarding the installation of electrical equipment in the country where the products are installed. For the terms of use of the information on the product info sheet see Conditions of Use.
