Call push button+7P DIN outlet white - 14502

Pdf
Vimar - 14502 - Call push button+7P DIN outlet white
Vimar - 14502 - Call push button+7P DIN outlet white

14502
Smart systems&products / Call-way / PLANA / Devices

Call push button+7P DIN outlet white
Call-way call push button with 7-contact DIN socket outlet for the connection of the mini-keyboard and red assurance indicator units, white - 2 modules

Product Status
3 - Active

Sheets, Manuals, Documentation

Drawings

view encumbered art. 14502
PNG DXF
rear view art. 14502
PNG DXF
3D view art. 14502
PNG DXF
Class group
Domestic switching devices
Class
Central-element clinic-installation
Suitable as central plate
No
Suitable for pull contact
No
Suitable for bus connection
No
Suitable for medical alarm
Single
Suitable for nurse call station
Yes
Colour
White
RAL-number (similar)
9003

00. CE Marking - EU

37. Marking - Morocco

46. UK PSTI compliance

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352135901
1 NR
6x5.4x5.3 [cm]
64.4 [g]
Barcode Qty 5 NR
8007352135918
5 NR
17.2x13.1x6 [cm]
380.13 [g]
