Vertical pocket badge switch white - 14465

Pdf

14465
Wiring devices / Traditional wiring devices / PLANA / Devices

Vertical pocket badge switch white
Electronic badge switch with vertical pocket, 16 A 250 V~ change-over relay output, supply voltage 230 V~ 50-60 Hz, 24 V~ 50-60 Hz and 24 Vdc (SELV), white - 3 modules. Provided without ISO card (badge)

Product Status
3 - Active

You may also be interested in

Class group
Alarm installations, emergency call and signalling
Class
Access control system
Standalone
Yes
Networkable
No
PC-binding
No
Type of interface
None
Reading strategy
Data medium
Signalling
None
Mounting method
Flush-mounted
Operating voltage AC 50 Hz
250,00 - 250,01 V
Operating voltage AC 60 Hz
250,00 - 250,01 V
Operating temperature
5 - 45 °C
Degree of protection (IP)
IP20
Colour
White
Material
Plastic
Width
67,50 mm
Height
49,00 mm
Depth
56,80 mm

00. CE Marking - EU

37. Marking - Morocco

37. Marking - Morocco

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352301979
1 NR
5.7x5.3x7.7 [cm]
90.8 [g]
Barcode Qty 5 NR
8007352738515
5 NR
21.4x11.6x6 [cm]
510.8 [g]
Barcode Qty 50 NR
8007352738522
50 NR
30.5x25.5x22.5 [cm]
5,416 [g]

Share

Codice QR scheda articolo

Legal

Vimar reserves the right to change at any time and without notice the characteristics of the products reported. Installation should be carried out by qualified staff in compliance with the current regulations regarding the installation of electrical equipment in the country where the products are installed. For the terms of use of the information on the product info sheet see Conditions of Use.
