14393
Wiring devices / Traditional wiring devices / PLANA / Devices
Emergency lighting device 120V
Emergency lighting fitting, 120 V~ 50-60 Hz, Ni-Cd rechargeable battery, provided with FD 4W G5 fluorescent lamp and mounting frame for 6/7-module flush mounting boxes. To complete with 7-module cover plate
Product Status
2 - Will be discontinued
Sheets, Manuals, Documentation
Class group
Luminaires
Luminaires
Class
Emergency luminaire
Emergency luminaire
Mounting method
Built-in
Built-in
Monitoring equipment
None
None
With remote switch connection
No
No
Power supply system
Peripheral (individual battery)
Peripheral (individual battery)
Battery technology
NiCd
NiCd
Lamp type
Fluorescent lamp
Fluorescent lamp
With light source
Yes
Yes
Housing material
Plastic
Plastic
Housing colour
White
White
Material cover
Without cover
Without cover
Voltage type
AC
AC
Nominal voltage
120,00 - 120,01 V
120,00 - 120,01 V
Degree of protection (IP)
IP40
IP40
Protection class according to IEC 61140
II
II
Max. system power
4,00 W
4,00 W
Rated luminous flux according to IEC 62722-2-1
26
26
Width
203,40 mm
203,40 mm
Height/depth
74,00 mm
74,00 mm
Built-in width
203,40 mm
203,40 mm
Built-in height/depth
47,10 mm
47,10 mm
Minimum order quantity: 1 NR
Barcode

8007352146648
1 NR
21.4x6.6x9.3 [cm]
488.53 [g]
Share
Legal
Vimar reserves the right to change at any time and without notice the characteristics of the products reported. Installation should be carried out by qualified staff in compliance with the current regulations regarding the installation of electrical equipment in the country where the products are installed. For the terms of use of the information on the product info sheet see Conditions of Use.
