Polarized 2P 6A 24A SELV outlet white - 14332

Pdf
Vimar - 14332 - Polarized 2P 6A 24A SELV outlet white
Vimar - 14332 - Polarized 2P 6A 24A SELV outlet white

14332
Wiring devices / Traditional wiring devices / PLANA / Devices

Polarized 2P 6A 24A SELV outlet white
Polarized 2P 6 A 24 V (SELV) socket outlet for plug 01099, white

Product Status
2 - Will be discontinued

Drawings

view encumbered art. 14332
PNG DXF
rear view art. 14332
PNG DXF
3D view art. 14332
PNG DXF
Class group
Domestic switching devices
Class
Socket outlet
With hinged lid
No
Colour
White
RAL-number (similar)
9003
Metallic colour
No
Transparent
No
Lockable
No
Nominal current
6 A
Nominal voltage
24 V
Device depth
33,50 mm

00. CE Marking - EU

99. WEEE Directive

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352108844
1 NR
4.1x2.8x5.3 [cm]
23.7 [g]
Barcode Qty 20 NR
8007352108851
20 NR
21.4x11.6x6 [cm]
526.33 [g]
Barcode Qty 200 NR
8007352640047
200 NR
30.5x25.5x22.5 [cm]
5,600 [g]
Question: Which pin is the positive and which one is the negative?
Answer: The single flat pin is the ˝+˝ and the L-shaped one is the ˝-˝.
