2P+E13A SICURY multi-outlet+switch white - 14255

Pdf
Vimar - 14255 - 2P+E13A SICURY multi-outlet+switch white
Vimar - 14255 - 2P+E13A SICURY multi-outlet+switch white

14255
Wiring devices / Traditional wiring devices / PLANA / Devices

2P+E13A SICURY multi-outlet+switch white
2P+E 13 A 250 V~ SICURY socket outlet, multi standard with 1P 1-way switch, lightable, white - 3 modules

Product Status
3 - Active

Sheets, Manuals, Documentation

Drawings

view encumbered art. 14255
PNG DXF
rear view art. 14255
PNG DXF
3D view art. 14255
PNG DXF
Class group
Domestic switching devices
Class
Socket outlet
Model
Other
Number of modules (module system)
2
Number of socket outlets switchable
1
Imprint/indication
None
Connection type
Screwed terminal
With hinged lid
No
With enhanced contact protection
Yes
Label space/information surface
Yes
Colour
White
RAL-number (similar)
9003
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
With function lighting
Yes
Over voltage protection
No
Fault current protection
No
Mounting method
Flush-mounted
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Glossy
With loop through function
No
With on/off switch
Yes
Rotated central insert
No
Nominal current
13 A
Nominal voltage
250 V
Frequency
50,00 - 60,00 HZ
Suitable for degree of protection (IP)
IP20
Impact strength
Other
Device width
67,30 mm
Device height
49,00 mm
Device depth
31,10 mm

00. CE Marking - EU

00. CE Marking - EU

37. Marking - Morocco

92. RoHS UAE

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352603721
1 NR
5.3x3.9x7.6 [cm]
66.8 [g]
Barcode Qty 10 NR
8007352603738
10 NR
28.1x13.1x6 [cm]
749.8 [g]
Barcode Qty 120 NR
8007352717268
120 NR
38.5x29x30 [cm]
8,997.6 [g]
