IoT connected radar sensor 1M Silver - 14179.SL

Pdf
Vimar - 14179.SL - IoT connected radar sensor 1M Silver
Vimar - 14179.SL - IoT connected radar sensor 1M Silver

14179.SL
Wiring devices / View Wireless wiring devices / PLANA / Devices

IoT connected radar sensor 1M Silver

Product Status
3 - Active

Class group
Domestic switching devices
Class
Movement sensor/presence detector complete
Model
Movement sensor
Sensor type
High frequency
With DALI interface
No
Constant light control
No
HVAC-control
No
Forced switch on
Yes
Forced switch off
No
Animal zone
Yes
Creep-under protection
No
Networkable
Yes
Scan angle
100
Staircase light controller
No
Bridging switch
No
Max. reach frontally
7 m
Suitable for wireless transmission
Yes
Remote operation
Yes
With remote control
No
Response value sensitivity adjustable
Yes
With signal unit
Yes
Teach-function for response value luminosity
No
Dim function with dimmer basic element
No
Mounting method
Flush-mounted
Suitable for ceiling mounting
No
Connection type
Screwed terminal
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Glossy
Anti-bacterial treatment
No
Colour
Silver
RAL-number (similar)
9006
Transparent
No
Degree of protection (IP)
IP40
Voltage type
AC
Frequency
50 - 60 HZ
Min. switch-on time
70 s
Switch-off delay
1.080 s
Detection angle horizontal
0 - 100
Max. switching power
960,00 W
Temperature
10 - 40 °C
Number of switching zones
1
Min. starting current
0 A
Substation input
No
With alarm function
Yes
Width
2.230,00 mm
Height
49,00 mm
Depth
4.950,00 mm
Diameter
0,00 mm
Built-in depth
3.900,00 mm
Built-in diameter
0,00 mm
Compatible with Apple HomeKit
Yes
Compatible with Google Assistant
Yes
Compatible with Amazon Alexa
Yes

00. CE Marking - EU

00. CE Marking - EU

01. IMQ - Italy

37. Marking - Morocco

40. Bluetooth technology

46. UK PSTI compliance

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352709317
1 NR
6x5.4x5.2 [cm]
46.6 [g]
Barcode Qty 10 NR
8007352709324
10 NR
28.1x13.1x6 [cm]
542.8 [g]
