SLAVE dimmer 230V 400VA 2M white - 14168

Pdf
Vimar - 14168 - SLAVE dimmer 230V 400VA 2M white
Vimar - 14168 - SLAVE dimmer 230V 400VA 2M white

14168
Wiring devices / Traditional wiring devices / PLANA / Devices

SLAVE dimmer 230V 400VA 2M white
SLAVE dimmer 230 V~ for: 40-400 VA to 50 Hz or 40-300 VA to 60 Hz electronic transfomers, neutral terminal, control via 14167 und 20167 , MOSFET+TRIAC technology, protection fuse, white - 2 modules

Product Status
2 - Will be discontinued

Sheets, Manuals, Documentation

Drawings

view encumbered art. 14168
PNG DXF
rear view art. 14168
PNG DXF
3D view art. 14168
PNG DXF
Class group
Domestic switching devices
Class
Dimmer
Method of operation
Other
Type of load
Capacitive load
Applicable with button
No
Applicable with movement sensor
No
Applicable with presence indicator
No
Applicable with time switch/timer
No
Applicable with transmission button
No
Applicable with infrared button
No
Mounting method
Flush-mounted
Type of fastening
Snapper mounting
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated
Surface finishing
Glossy
Colour
White
RAL-number (similar)
9003
Transparent
No
Suitable for degree of protection (IP)
IP40
Nominal voltage
230,00 - 230,01 V
Frequency
50,00 - 60,00 HZ
Control voltage
230,00 - 230,01 V
Device width
44,80 mm
Device height
49,00 mm
Device depth
43,00 mm

37. Marking - Morocco

96. Electrotechnical expert

Minimum order quantity: 5 NR

Barcode

Barcode Qty 1 NR
8007352387782
1 NR
6x5.4x5.3 [cm]
71.7 [g]
Barcode Qty 5 NR
8007352387799
5 NR
17.2x13.1x6 [cm]
414.7 [g]
