1P NO 10A push button+green pilot Silver - 14068.V.SL

Pdf
Vimar - 14068.V.SL - 1P NO 10A push button+green pilot Silver
Vimar - 14068.V.SL - 1P NO 10A push button+green pilot Silver

14068.V.SL
Wiring devices / Traditional wiring devices / PLANA / Devices

1P NO 10A push button+green pilot Silver
1P NO 10 A 250 V~ push button + indicator for signalling unit, green diffuser, Silver. Provided without signalling unit

Product Status
2 - Will be discontinued

Drawings

view encumbered art. 14068.V.SL
PNG DXF
rear view art. 14068.V.SL
PNG DXF
3D view art. 14068.V.SL
PNG DXF
Class group
Domestic switching devices
Class
Push button
Model
Single push button
Method of operation
Push button
Number of rockers
1
Number of modules (module system)
100
Number of poles
1
Nominal voltage
250 V
Rated current
10,00 A
With lighting
Yes
Feedback-signal contact
No
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Surface protection
Lacquered
Surface finishing
Glossy
Colour
Silver
RAL-number (similar)
9006
Transparent
No
Label space/information surface
Yes
Device width
22,30 mm
Device height
49,00 mm
Device depth
38,40 mm

00. CE Marking - EU

14. TSE - Turkey

19. NOM - Mexico

29. QCERT - Colombia

37. Marking - Morocco

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352321045
1 NR
4.1x2.8x5.3 [cm]
31.27 [g]
Barcode Qty 20 NR
8007352321052
20 NR
21.4x11.6x6 [cm]
684.1 [g]
