Vimar - 14062 - Two interlocked 1P NO+NO 10A pushes w

14062
Wiring devices / Traditional wiring devices / PLANA / Devices

Two interlocked 1P NO+NO 10A pushes w
Two interlocked push buttons, 1P NO + 1P NO 10 A 250 V~, with directional arrows, white

Product Status
3 - Active

Drawings

view encumbered art. 14062

PNG DXF

rear view art. 14062

PNG DXF

3D view art. 14062

PNG DXF

Class group
Domestic switching devices

Class
Push button

Assembly arrangement
Modular device for domestic switching devices

Model
Other

Method of operation
Push button

Number of rockers
1

Number of modules (module system)
100

Number of poles
1

Nominal voltage
250 V

Rated current
10,00 A

With lighting
No

Feedback-signal contact
No

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Untreated

Surface finishing
Glossy

Colour
White

RAL-number (similar)
9003

Transparent
No

Label space/information surface
Yes

Suitable for degree of protection (IP)
IP40

Device width
22,30 mm

Device height
49,00 mm

Device depth
37,00 mm

00. CE Marking - EU

01. IMQ - Italy

07. INGCER - Chile

14. TSE - Turkey

15. CCC - China

19. NOM - Mexico

20. IQC - Argentina

28. NSW - Australia

29. QCERT - Colombia

31. TISI - Thailand

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 20 NR

Barcode

8007352117310

1 NR

4.1x2.8x5.3 [cm]

32.8 [g]

8007352117327

20 NR

21.4x11.6x6 [cm]

713.23 [g]

8007352361348

200 NR

30.5x26x22 [cm]

7,472.3 [g]
