2P 16AX 1-way switch mechanism - 14015.0

Pdf
Vimar - 14015.0 - 2P 16AX 1-way switch mechanism
Vimar - 14015.0 - 2P 16AX 1-way switch mechanism

14015.0
Wiring devices / Traditional wiring devices / PLANA / Devices

2P 16AX 1-way switch mechanism
2P 16 AX 250 V~ 1-way switch mechanism, lightable, to complete with 1, 2 or 3-module button. Max 200 W for self-ballasted lamps (IEC 60669-1:2017)

Product Status
3 - Active

Drawings

view encumbered art. 14015.0
PNG DXF
rear view art. 14015.0
PNG DXF
3D view art. 14015.0
PNG DXF
Class group
Domestic switching devices
Class
Installation switch
Wiring system
2-pole switch
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Glossy
Colour
Green
RAL-number (similar)
9003
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 V
Rated current
16,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
Yes
Device width
22,30 mm
Device height
49,00 mm
Device depth
38,70 mm
Built-in depth
24,00 mm

00. CE Marking - EU

01. IMQ - Italy

14. TSE - Turkey

15. CCC - China

19. NOM - Mexico

20. IQC - Argentina

28. NSW - Australia

29. QCERT - Colombia

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 50 NR

Barcode

Barcode Qty 1 NR
8007352106611
1 NR
4.1x2.8x5.3 [cm]
30.67 [g]
Barcode Qty 50 NR
8007352118737
50 NR
21.6x11.6x14.3 [cm]
1,597.27 [g]
Barcode Qty 500 NR
8007352640795
500 NR
57.5x22.5x30 [cm]
16,520 [g]
