1P NC 10A push button white - 14010

Pdf

Vimar - 14010 - 1P NC 10A push button white

14010
Wiring devices / Traditional wiring devices / PLANA / Devices

1P NC 10A push button white
1P NC 10 A 250 V~ push button, lightable, replaceable button, white

Product Status
3 - Active

Drawings

view encumbered art. 14010

PNG DXF

rear view art. 14010

PNG DXF

3D view art. 14010

PNG DXF

Class group
Domestic switching devices

Class
Push button

Assembly arrangement
Modular device for domestic switching devices

Model
Single push button

Method of operation
Push button

Number of rockers
1

Number of modules (module system)
100

Number of poles
1

Nominal voltage
250 V

Rated current
10,00 A

With lighting
Yes

Feedback-signal contact
No

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Untreated

Surface finishing
Glossy

Colour
White

RAL-number (similar)
9003

Transparent
No

Label space/information surface
Yes

Suitable for degree of protection (IP)
IP40

Device width
22,30 mm

Device height
49,00 mm

Device depth
38,70 mm

00. CE Marking - EU

01. IMQ - Italy

14. TSE - Turkey

15. CCC - China

19. NOM - Mexico

20. IQC - Argentina

28. NSW - Australia

29. QCERT - Colombia

31. TISI - Thailand

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 10 NR

Barcode

8007352117259

1 NR

4.1x2.8x5.3 [cm]

27.7 [g]

8007352263680

10 NR

14.4x9x6 [cm]

317.07 [g]

8007352634169

160 NR

37.5x30x13.5 [cm]

5,073.6 [g]
