Three 1P 20AX 1-way switches white - 14003

Pdf
Vimar - 14003 - Three 1P 20AX 1-way switches white
Vimar - 14003 - Three 1P 20AX 1-way switches white

14003
Wiring devices / Traditional wiring devices / PLANA / Devices

Three 1P 20AX 1-way switches white
Three 1P 20 AX 250 V~ 1-way switches, lightable, white - 2 modules. Max 250 W for self-ballasted lamps (IEC 60669-1:2017)

Product Status
3 - Active

Drawings

view encumbered art. 14003
PNG DXF
rear view art. 14003
PNG DXF
3D view art. 14003
PNG DXF
Class group
Domestic switching devices
Class
Installation switch
Wiring system
Off switch 1-pole
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
2
Push button switch
Yes
Number of rockers
3
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Glossy
Colour
White
RAL-number (similar)
9003
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 V
Rated current
20,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
Device width
44,80 mm
Device height
49,00 mm
Device depth
38,40 mm
Built-in depth
24,00 mm

00. CE Marking - EU

01. IMQ - Italy

13. SNI-MGI - Indonesia

15. CCC - China

19. NOM - Mexico

31. TISI - Thailand

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352403949
1 NR
5.1x4.3x5.3 [cm]
60.9 [g]
Barcode Qty 20 NR
8007352403956
20 NR
26.9x11.6x9 [cm]
1,309 [g]
Barcode Qty 240 NR
8007352641778
240 NR
38x28.5x35.5 [cm]
16,236 [g]
