Self-bearing plate 5M box 5M - 10739

Pdf
Vimar - 10739 - Self-bearing plate 5M box 5M
Vimar - 10739 - Self-bearing plate 5M box 5M

10739
Wiring devices / Traditional wiring devices / LINEA Classica / Cover plates

Self-bearing plate 5M box 5M
5-module self-bearing cover plate, resin, with screws, for 3-module flush mounting boxes, ivory. Provided with screw covering strips 10798.01

Product Status
3 - Active

Class group
Domestic switching devices
Class
Cover frame for domestic switching devices
Number of units
5
Mounting direction
Horizontal and vertical
Number of units horizontal
5
Number of units vertical
1
Number of modules horizontal (module system)
5
Number of modules vertical (module system)
1
With mounting grid
Yes
Suitable for subfloor installation duct box
Yes
Suitable for wall duct
Yes
Suitable for built-in installation
Yes
Label space/information surface
Yes
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
White
RAL-number (similar)
9003
Transparent
No
With hinged lid
No
Degree of protection (IP)
IP00
Type of fastening
Clamp mounting
Width
164,50 mm
Height
76,00 mm
Built-in width
164,50 mm
Built-in height
76,00 mm
Diameter bore hole (opening)
0 mm

00. CE Marking - EU

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352044142
1 NR
16.4x7.6x2 [cm]
39.87 [g]
Barcode Qty 10 NR
8007352019553
10 NR
17.9x17x8.5 [cm]
476.4 [g]
