Self-bearing plate 2M box 3M - 10736

Pdf
Vimar - 10736 - Self-bearing plate 2M box 3M
Vimar - 10736 - Self-bearing plate 2M box 3M

10736
Wiring devices / Traditional wiring devices / LINEA Classica / Cover plates

Self-bearing plate 2M box 3M
2-module self-bearing cover plate, resin, with screws, for 3-module flush mounting boxes, ivory. Provided with screw covering strips 10797.01

Product Status
3 - Active

Class group
Domestic switching devices
Class
Cover frame for domestic switching devices
Number of units
3
Mounting direction
Horizontal and vertical
Number of units horizontal
3
Number of units vertical
1
Number of modules horizontal (module system)
2
Number of modules vertical (module system)
1
With mounting grid
Yes
Suitable for subfloor installation duct box
Yes
Suitable for wall duct
Yes
Suitable for built-in installation
Yes
Label space/information surface
Yes
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
White
RAL-number (similar)
9003
Transparent
No
With hinged lid
No
Degree of protection (IP)
IP00
Type of fastening
Clamp mounting
Width
120,00 mm
Height
76,00 mm
Built-in width
120,00 mm
Built-in height
76,00 mm
Diameter bore hole (opening)
0 mm

00. CE Marking - EU

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352044098
1 NR
12x7.8x2 [cm]
28.6 [g]
Barcode Qty 20 NR
8007352001947
20 NR
25x18.9x8.4 [cm]
683.47 [g]
Barcode Qty 280 NR
8007352335554
280 NR
59.5x38.5x26.5 [cm]
10,363.33 [g]

Share

Codice QR scheda articolo

Legal

Vimar reserves the right to change at any time and without notice the characteristics of the products reported. Installation should be carried out by qualified staff in compliance with the current regulations regarding the installation of electrical equipment in the country where the products are installed. For the terms of use of the information on the product info sheet see Conditions of Use.
