Surface-box+bottom 3M 40mm depth - 09968

Pdf
Vimar - 09968 - Surface-box+bottom 3M 40mm depth
Vimar - 09968 - Surface-box+bottom 3M 40mm depth

09968
System infrastructure / Enclosures and control units / Connector block boxes / Surface mounting

Surface-box+bottom 3M 40mm depth
3-module surface or table mounting box with backplate, 40 mm depth, for 8000, Linea and 7000 with relevants mounting frames, cover plates or self-bearing cover plates. Not suitable for 08065..., 08081..., 08341, 08342, 08440, 08441, 08443, 08445, 08446, 08448, 08450, 08470, 08480, 08481, 10064..., 10065..., 10081...

Product Status
3 - Active

Sheets, Manuals, Documentation

Class group
Connection material (electrotechnical)
Class
Box/housing for surface mounting on the wall/ceiling
Max. conductor cross section
0
Equipped with
None
Shape
Rectangular
Mounting method
Wall-/ceiling mounting
Mounting in the soil
No
Mounting under water
No
For tube diameter
20/25 mm
Inlet from the rear
Yes
Length
80,00 mm
Width
124,00 mm
Depth
40,00 mm
Diameter
0 mm
Tackable
No
Number of inlets
6
Type of housing feed-through
None
Material
Plastic
Halogen free
No
Surface protection
Untreated
Colour
White
Degree of protection (IP)
IP20
Cover model
Other
Transparent cover
No
Cover attachment
Screwed
Castable
No
With casting compound
No
Sealable
No
Rated insulation voltage Ui
450 V
Circuit integrity
None
With screening
No
Weatherproof
No
Operating temperature
0 - 60 °C
Explosion-tested version
No
For Ex-zone gas
None
For Ex-Zone dust
None

00. CE Marking - EU

01. IMQ - Italy

37. Marking - Morocco

96. Electrotechnical expert

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352043831
1 NR
12.5x8.1x4 [cm]
78.07 [g]
Barcode Qty 20 NR
8007352003453
20 NR
28.4x24.4x16.4 [cm]
1,784.67 [g]
Barcode Qty 80 NR
8007352368767
80 NR
59.5x38.5x26.5 [cm]
7,938.68 [g]
