Plate 4M techn.slate grey - 09674.03

Pdf
Vimar - 09674.03 - Plate 4M techn.slate grey
Vimar - 09674.03 - Plate 4M techn.slate grey

09674.03
Wiring devices / Traditional wiring devices / NEVE UP / Cover plates

Plate 4M techn.slate grey
4-module cover plate for 4-module mounting boxes, technopolymer, slate grey

Product Status
3 - Active

You may also be interested in

09614
09614 - Frame 4M +screws

Drawings

view encumbered art. 09674.03
PNG DXF
rear view art. 09674.03
PNG DXF
3D view art. 09674.03
PNG DXF
Class group
Domestic switching devices
Class
Cover frame for domestic switching devices
Number of units
4
Mounting direction
Horizontal and vertical
Number of units horizontal
4
Number of units vertical
1
Number of modules horizontal (module system)
4
Number of modules vertical (module system)
1
With mounting grid
Yes
Suitable for subfloor installation duct box
Yes
Suitable for wall duct
Yes
Suitable for built-in installation
Yes
Label space/information surface
Yes
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated
Surface finishing
Glossy
Colour
Grey
RAL-number (similar)
7043
Transparent
No
With hinged lid
No
Type of fastening
Clamp mounting
Width
142,40 mm
Height
86,00 mm
Depth
8,40 mm
Built-in width
142,40 mm

00. CE Marking - EU

29. QCERT - Colombia

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352663039
1 NR
15.5x9.9x0.9 [cm]
18.9 [g]
Barcode Qty 10 NR
8007352663046
10 NR
18x9.5x9.7 [cm]
247.3 [g]
Barcode Qty 240 NR
8007352669840
240 NR
41x32x39.5 [cm]
6,568.2 [g]
