Vimar - 09671.24 - Plate 1centrM techn.matt copper
Vimar - 09671.24 - Plate 1centrM techn.matt copper

09671.24
Wiring devices / Traditional wiring devices / NEVE UP / Cover plates

Plate 1centrM techn.matt copper
1-module central cover plate for 3-module mounting boxes, technopolymer, matt copper

Product Status
3 - Active

You may also be interested in

09613
09613 - Frame 3M +screws
09623
09623 - Mounting frame Plana/Neve+screws

Drawings

view encumbered art. 09671.24
PNG DXF
rear view art. 09671.24
PNG DXF
3D view art. 09671.24
PNG DXF
Class group
Domestic switching devices
Class
Cover frame for domestic switching devices
Number of units
1
Mounting direction
Horizontal and vertical
Number of units horizontal
1
Number of units vertical
1
Number of modules horizontal (module system)
1
Number of modules vertical (module system)
1
With mounting grid
Yes
Suitable for subfloor installation duct box
Yes
Suitable for wall duct
Yes
Suitable for built-in installation
Yes
Label space/information surface
Yes
Material
Plastic
Material quality
Thermoplastic
Surface protection
Lacquered
Surface finishing
Matt
Colour
Copper
RAL-number (similar)
8029
Transparent
No
With hinged lid
No
Type of fastening
Clamp mounting
Width
120,00 mm
Height
86,00 mm
Depth
8,90 mm
Built-in width
120,00 mm

00. CE Marking - EU

29. QCERT - Colombia

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352662735
1 NR
13x9x0.9 [cm]
20.13 [g]
Barcode Qty 10 NR
8007352662742
10 NR
17.1x9.8x9.9 [cm]
254.53 [g]
Barcode Qty 360 NR
8007352670273
360 NR
59x34.5x32.5 [cm]
9,913.08 [g]
