Plate 1centrMx2M techn.white - 09661.01

Pdf
Vimar - 09661.01 - Plate 1centrMx2M techn.white
Vimar - 09661.01 - Plate 1centrMx2M techn.white

09661.01
Wiring devices / Traditional wiring devices / NEVE UP / Cover plates

Plate 1centrMx2M techn.white
1-module central cover plate for 2-module mounting boxes, technopolymer, white

Product Status
3 - Active

You may also be interested in

09602.1
09602.1 - Frame 2M +claws 71mm
09603.1
09603.1 - Frame 2M wihtout screws 71mm

Drawings

view encumbered art. 09661.01
PNG DXF
rear view art. 09661.01
PNG DXF
3D view art. 09661.01
PNG DXF
Class group
Domestic switching devices
Class
Cover frame for domestic switching devices
Number of units
1
Mounting direction
Horizontal and vertical
Number of units horizontal
1
Number of units vertical
1
Number of modules horizontal (module system)
1
Number of modules vertical (module system)
1
With mounting grid
Yes
Suitable for subfloor installation duct box
Yes
Suitable for wall duct
Yes
Suitable for built-in installation
Yes
Label space/information surface
Yes
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated
Surface finishing
Glossy
Colour
White
RAL-number (similar)
9016
Transparent
No
With hinged lid
No
Type of fastening
Clamp mounting
Width
86,00 mm
Height
86,00 mm
Depth
8,80 mm
Built-in width
86,00 mm

00. CE Marking - EU

29. QCERT - Colombia

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352660632
1 NR
10x9x0.5 [cm]
14.73 [g]
Barcode Qty 10 NR
8007352660649
10 NR
14.1x9.8x9.9 [cm]
195 [g]
Barcode Qty 160 NR
8007352670242
160 NR
39x29.5x22 [cm]
3,610 [g]
