IoT dial thermostat 2M white - 09473

Pdf
Vimar - 09473 - IoT dial thermostat 2M white
Vimar - 09473 - IoT dial thermostat 2M white

09473
Wiring devices / View Wireless wiring devices / NEVE UP / Devices

IoT dial thermostat 2M white
Dial thermostat for ambient temperature control, 5(2) A 240 V~ relay output, View Wireless technology on Bluetooth® wireless technology 5.0 for mesh View Wireless system realization, 1 input for outer temperature sensor, supply voltage 100-240 V~ 50/60 Hz, heating and air-conditioning ON/OFF and PID, class I temperature control device (contribution 1%) in ON/OFF mode, class IV (contribution 2%) in PID mode, white LED backlighting and brightness regulation, supply voltage 100-240 V 50/60 Hz, white - 2 modules

Product Status
3 - Active

Class group
Stats, switches and controllers
Class
Room thermostat
Model
Other
Type of power supply
230 V AC
Connection
3-/4-wire
With receiver
No
External sensor
Yes
Thermal feedback
Parallel
Control characteristic
PID
Suitable for heating
Yes
Number of heater outputs
1
Number of cooler outputs
1
Adjustable differential
Yes
Temperature readable
Yes
With sound indicator
No
Sensor/feeler type
Other
Mounting method
Other
Number of modules (module system)
2
With display
Yes
Operation
Turn
With tap water circuit
No
Max. contact voltage
240 V
Max. contact load
5 A
Degree of protection (IP)
IP30
Explosion-proof
No
Colour
White
RAL-number
9003
Height
47,00 mm
Width
44,80 mm
Depth
41,50 mm
Class of the temperature control
IV

00. CE Marking - EU

00. CE Marking - EU

37. Marking - Morocco

40. Bluetooth technology

42. Zigbee certified

46. UK PSTI compliance

99. WEEE Directive

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352671386
1 NR
5.7x5.3x7.7 [cm]
87 [g]
Barcode Qty 60 NR
8007352746534
60 NR
37.5x30x13.5 [cm]
5,580 [g]
