Double indicator unit room-status carbon - 09388.SC.CM

Pdf
Vimar - 09388.SC.CM - Double indicator unit room-status carbon
Vimar - 09388.SC.CM - Double indicator unit room-status carbon

09388.SC.CM
Wiring devices / Traditional wiring devices / NEVE UP / Devices

Double indicator unit room-status carbon

Product Status
3 - Active

Drawings

view encumbered art. 09388.SC.CM
PNG DXF
rear view art. 09388.SC.CM
PNG DXF
3D view art. 09388.SC.CM
PNG DXF
Class group
Domestic switching devices
Class
Information light signal for domestic switching devices
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Lamp holder
Other
With light source
No
Lamp type
LED exchangeable
With flashlight
No
With fixed symbol/imprint
No
With exchangeable symbol
No
Application as button
No
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Matt
Colour
Anthracite
RAL-number (similar)
7016
Transparent
No
Colour light source
White
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 V

00. CE Marking - EU

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352722040
1 NR
4.1x2.8x5.3 [cm]
22.66 [g]
Barcode Qty 20 NR
8007352722057
20 NR
21.4x11.6x6 [cm]
508.39 [g]
Barcode Qty 200 NR
8007352722064
200 NR
30.5x25.5x22.5 [cm]
5,400 [g]
