Vimar - 09245 - 2P+E 15A USA+SASO outlet white
Vimar - 09245 - 2P+E 15A USA+SASO outlet white

09245
Wiring devices / Traditional wiring devices / NEVE UP / Devices

2P+E 15A USA+SASO outlet white
2P+E 15 A 127 V~ socket outlet, American and Saudi Arabian standards, white

Product Status
3 - Active

You may also be interested in

09242
09242 - 2P+E 15A USA+SASO SICURY outlet white

Drawings

view encumbered art. 09245
PNG DXF
rear view art. 09245
PNG DXF
3D view art. 09245
PNG DXF
Class group
Domestic switching devices
Class
Socket outlet
Number of modules (module system)
1
Number of socket outlets switchable
0
Imprint/indication
None
Connection type
Screwed terminal
With hinged lid
No
With enhanced contact protection
No
Label space/information surface
Yes
Colour
White
RAL-number (similar)
9003
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
With function lighting
No
Over voltage protection
No
Fault current protection
No
Mounting method
Flush-mounted
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Glossy
With loop through function
No
With on/off switch
No
Rotated central insert
No
Nominal current
15 A
Nominal voltage
127 V
Frequency
50,00 - 60,00 HZ
Suitable for degree of protection (IP)
IP20
Impact strength
Other
Device width
22,30 mm
Device height
47,00 mm
Device depth
36,50 mm

00. CE Marking - EU

29. QCERT - Colombia

37. Marking - Morocco

99. WEEE Directive

Minimum order quantity: 50 NR

Barcode

Barcode Qty 1 NR
8007352296329
1 NR
4.1x2.8x5.3 [cm]
27.2 [g]
Barcode Qty 50 NR
8007352296336
50 NR
21.4x11.6x14.2 [cm]
1,449.93 [g]
Barcode Qty 500 NR
8007352296343
500 NR
57.5x22.5x30 [cm]
15,038 [g]
