Two 2P+E15AUSA+SASO SICURY outlets white - 09243

Pdf
Vimar - 09243 - Two 2P+E15AUSA+SASO SICURY outlets white
Vimar - 09243 - Two 2P+E15AUSA+SASO SICURY outlets white

09243
Wiring devices / Traditional wiring devices / NEVE UP / Devices

Two 2P+E15AUSA+SASO SICURY outlets white
Double 2P+E 15 A 127 V~SICURY socket outlet, American and Saudi Arabian standards, white - 3 modules

Product Status
3 - Active

Drawings

view encumbered art. 09243
PNG DXF
rear view art. 09243
PNG DXF
3D view art. 09243
PNG DXF
Class group
Domestic switching devices
Class
Socket outlet
Number of modules (module system)
3
Number of socket outlets switchable
0
Imprint/indication
None
Connection type
Screwed terminal
With hinged lid
No
With enhanced contact protection
Yes
Label space/information surface
Yes
Colour
White
RAL-number (similar)
9003
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
With function lighting
No
Over voltage protection
No
Fault current protection
No
Mounting method
Flush-mounted
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Glossy
With loop through function
No
With on/off switch
No
Rotated central insert
No
Nominal current
15 A
Nominal voltage
127 V
Frequency
50,00 - 60,00 HZ
Suitable for degree of protection (IP)
IP20
Impact strength
Other
Device width
67,30 mm
Device height
47,00 mm
Device depth
35,50 mm

00. CE Marking - EU

29. QCERT - Colombia

37. Marking - Morocco

99. WEEE Directive

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352296299
1 NR
5.3x3.9x7.6 [cm]
57.8 [g]
Barcode Qty 10 NR
8007352296305
10 NR
28.1x13.1x6 [cm]
654.4 [g]
Barcode Qty 120 NR
8007352296312
120 NR
38.5x29x30 [cm]
8,286 [g]
