2P 16A USA+EU ø4,8mm SICURY outletcarbon - 09234.CM

Pdf
Vimar - 09234.CM - 2P 16A USA+EU ø4,8mm SICURY outletcarbon
Vimar - 09234.CM - 2P 16A USA+EU ø4,8mm SICURY outletcarbon

09234.CM
Wiring devices / Traditional wiring devices / NEVE UP / Devices

2P 16A USA+EU ø4,8mm SICURY outletcarbon
2P 16 A 250 V~ SICURY socket outlet, Euro-American standard (parallel flat pins and ø 4.8 mm pins), carbon matt

Product Status
3 - Active

Drawings

view encumbered art. 09234.CM
PNG DXF
rear view art. 09234.CM
PNG DXF
3D view art. 09234.CM
PNG DXF
Class group
Domestic switching devices
Class
Socket outlet
Model
Other
Number of modules (module system)
1
With hinged lid
No
Label space/information surface
Yes
Colour
Anthracite
RAL-number (similar)
7016
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
Mounting method
Flush-mounted
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated
Surface finishing
Matt
Anti-bacterial treatment
No
With loop through function
No
With on/off switch
No
Rotated central insert
No
Nominal current
16 A
Nominal voltage
250 V
Frequency
50,00 - 60,00 HZ
Device width
22,30 mm
Device height
47,00 mm
Device depth
39,50 mm

00. CE Marking - EU

37. Marking - Morocco

99. WEEE Directive

Minimum order quantity: 50 NR

Barcode

Barcode Qty 1 NR
8007352666047
1 NR
4.1x2.8x5.3 [cm]
27.93 [g]
Barcode Qty 50 NR
8007352666054
50 NR
21.4x11.6x14.2 [cm]
1,492.33 [g]
Barcode Qty 500 NR
8007352666061
500 NR
57.5x22.5x30 [cm]
15,496 [g]
