2P+E 16A P30 outlet white - 09209

Pdf
Vimar - 09209 - 2P+E 16A P30 outlet white
Vimar - 09209 - 2P+E 16A P30 outlet white

09209
Wiring devices / Traditional wiring devices / NEVE UP / Devices

2P+E 16A P30 outlet white
2P+E 16 A 250 V~ SICURY socket outlet, Italian standard P30 (lateral and central earth contacts), white - 2 modules

Product Status
3 - Active

You may also be interested in

09210
09210 - 2P+E 16A universal outlet white

Drawings

view encumbered art. 09209
PNG DXF
rear view art. 09209
PNG DXF
3D view art. 09209
PNG DXF
Class group
Domestic switching devices
Class
Socket outlet
Model
Italian type P30
Number of modules (module system)
2
Number of socket outlets switchable
0
Imprint/indication
None
Connection type
Screwed terminal
With hinged lid
No
With enhanced contact protection
Yes
Label space/information surface
Yes
Colour
White
RAL-number (similar)
9003
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
With function lighting
No
Over voltage protection
No
Fault current protection
No
Mounting method
Flush-mounted
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Glossy
With loop through function
No
With on/off switch
No
Rotated central insert
No
Nominal current
16 A
Nominal voltage
250 V
Frequency
50,00 - 60,00 HZ
Suitable for degree of protection (IP)
IP20
Impact strength
Other
Device width
22,30 mm
Device height
47,00 mm
Device depth
38,80 mm

00. CE Marking - EU

01. IMQ - Italy

07. INGCER - Chile

13. SNI-MGI - Indonesia

37. Marking - Morocco

99. WEEE Directive

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352296237
1 NR
5.1x4.3x5.3 [cm]
44.8 [g]
Barcode Qty 20 NR
8007352296244
20 NR
26.9x11.6x9 [cm]
991.47 [g]
Barcode Qty 240 NR
8007352296251
240 NR
38x28.5x35.5 [cm]
12,398.67 [g]
