IoT connected radar sensor 1M white - 09179

Pdf

09179
Wiring devices / View Wireless wiring devices / NEVE UP / Devices

IoT connected radar sensor 1M white

Product Status
3 - Active

Class group
Domestic switching devices
Class
Movement sensor/presence detector complete
Model
Movement sensor
Sensor type
High frequency
With DALI interface
No
Constant light control
No
HVAC-control
No
Forced switch on
Yes
Forced switch off
No
Animal zone
Yes
Creep-under protection
No
Networkable
Yes
Scan angle
100
Optimum mounting height
1,00 m
Staircase light controller
No
Bridging switch
No
Max. reach sideways
7 m
Max. presence range
45 m2
Max. reach frontally
7 m
Diameter reach on floor
0 m
Suitable for wireless transmission
Yes
Remote operation
Yes
With remote control
No
Response value sensitivity adjustable
Yes
Response value luminosity adjustable
No
With signal unit
Yes
Teach-function for response value luminosity
No
Dim function with dimmer basic element
No
Mounting method
Flush-mounted
Suitable for ceiling mounting
No
Connection type
Screwed terminal
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Anti-bacterial treatment
No
Colour
White
RAL-number (similar)
9003
Transparent
No
Degree of protection (IP)
IP40
Voltage type
AC
Frequency
50 - 60 HZ
Min. switch-on time
70 s
Max. duty cycle
0 min
Switch-off delay
1.080 s
Switching-on delay
0 s
Detection angle horizontal
0 - 100
Max. switching power
12,00 W
Max. switching power LED
12 W
Suitable for C-load
No
Temperature
10 - 40 °C
Number of switching zones
1
Max. starting current
0,00 A
Min. starting current
0 A
Control current
0 mA
Substation input
No
With alarm function
Yes
Width
22,30 mm
Height
47,00 mm
Depth
49,40 mm
Built-in width
22,30 mm
Built-in depth
39,90 mm
Built-in length
47,00 mm
Min. depth of built-in installation box
48 mm
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No

00. CE Marking - EU

37. Marking - Morocco

40. Bluetooth technology

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352732629
1 NR
5.2x3.5x5.3 [cm]
47 [g]
Barcode Qty 10 NR
8007352732636
10 NR
19x11.3x6.2 [cm]
528.4 [g]
