Two indep.1P NO+NO 10A pushes white - 09066

Pdf
Vimar - 09066 - Two indep.1P NO+NO 10A pushes white
Vimar - 09066 - Two indep.1P NO+NO 10A pushes white

09066
Wiring devices / Traditional wiring devices / NEVE UP / Devices

Two indep.1P NO+NO 10A pushes white

Product Status
3 - Active

Drawings

view encumbered art. 09066
PNG DXF
rear view art. 09066
PNG DXF
3D view art. 09066
PNG DXF
Class group
Domestic switching devices
Class
Push button
Assembly arrangement
Modular device for domestic switching devices
Model
Other
Method of operation
Push button
Number of contacts as normally closed contact
0
Number of contacts as normally open contact
2
Number of contacts as change-over contact
0
Number of revolving contacts
0
Contactless type
No
Number of rockers
2
Number of modules (module system)
1
Number of poles
1
Nominal voltage
250 V
Rated current
10,00 A
With lighting
No
With light source
No
With signal lamp
No
Feedback-signal contact
No
Connection type
Screwed terminal
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Anti-bacterial treatment
No
Surface protection
Untreated
Surface finishing
Glossy
Colour
White
RAL-number (similar)
9003
Transparent
No
Label space/information surface
Yes
Imprint
None
Suitable for degree of protection (IP)
IP40
Impact strength
Other
Device width
22,30 mm
Device height
47,00 mm
Device depth
38,50 mm
Min. depth of built-in installation box
35 mm
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No

00. CE Marking - EU

29. QCERT - Colombia

37. Marking - Morocco

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352726611
1 NR
4.1x2.8x5.3 [cm]
31.4 [g]
Barcode Qty 20 NR
8007352726628
20 NR
21.4x11.6x6 [cm]
682.84 [g]
Barcode Qty 200 NR
8007352726635
200 NR
30.5x25.5x22.5 [cm]
7,146 [g]
