2P 10AX switch carbon matt - 09060.CM

Pdf
Vimar - 09060.CM - 2P 10AX switch carbon matt
Vimar - 09060.CM - 2P 10AX switch carbon matt

09060.CM
Wiring devices / Traditional wiring devices / NEVE UP / Devices

2P 10AX switch carbon matt
2P 10 AX 250 V~ switch (6 terminals), with two buttons, with direction arrows and central OFF position, carbon matt. Max 100 W for self-ballasted lamps (IEC 60669-1:2017)

Product Status
3 - Active

You may also be interested in

09062.CM
09062.CM - Two interlocked 1P NO+NO 10A pushes carb

Drawings

view encumbered art. 09060.CM
PNG DXF
rear view art. 09060.CM
PNG DXF
3D view art. 09060.CM
PNG DXF
Class group
Domestic switching devices
Class
Push button
Assembly arrangement
Modular device for domestic switching devices
Model
Other
Method of operation
Other
Number of rockers
1
Number of modules (module system)
100
Number of poles
2
Nominal voltage
250 V
Rated current
10,00 A
Feedback-signal contact
No
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Anti-bacterial treatment
No
Surface protection
Lacquered
Surface finishing
Matt
Colour
Anthracite
RAL-number (similar)
7016
Transparent
No
Label space/information surface
Yes
Device width
22,30 mm
Device height
47,00 mm
Device depth
44,60 mm

00. CE Marking - EU

13. SNI-MGI - Indonesia

19. NOM - Mexico

29. QCERT - Colombia

29. QCERT - Colombia

37. Marking - Morocco

37. Marking - Morocco

99. WEEE Directive

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352665798
1 NR
5.1x2.8x5.3 [cm]
41.4 [g]
Barcode Qty 10 NR
8007352665804
10 NR
14.4x11.6x6 [cm]
456.4 [g]
Barcode Qty 120 NR
8007352665811
120 NR
37.5x30x13.5 [cm]
5,818 [g]
