1P NO 10A cord-operated push carbon matt - 09052.CM

Pdf
Vimar - 09052.CM - 1P NO 10A cord-operated push carbon matt
Vimar - 09052.CM - 1P NO 10A cord-operated push carbon matt

09052.CM
Wiring devices / Traditional wiring devices / NEVE UP / Devices

1P NO 10A cord-operated push carbon matt
1P NO 10 A 250 V~ push button, with pull-cord and 1.5 m cord and knob, carbon matt

Product Status
3 - Active

You may also be interested in

09470.CM
09470.CM - Dial thermostat 100-240V 2M carbon m
09026.PLS.CM
09026.PLS.CM - Button 1M +diffuser PLS symb.carbon matt
09026.DND.CM
09026.DND.CM - Button 1M +diffuser DND symb. carbon m
09463.CM
09463.CM - Vertical badge switch 2M carbon matt
09290.CM
09290.CM - Shaver supply unit 230V carbon matt
09465.CM
09465.CM - Vertical pocket badge switch carbon matt
09257.CM
09257.CM - 2P+E13ASICURY multistandard outlet carbo
09181.CM
09181.CM - IR relay-switch 230V carbon matt

Drawings

view encumbered art. 09052.CM
PNG DXF
rear view art. 09052.CM
PNG DXF
3D view art. 09052.CM
PNG DXF
Class group
Domestic switching devices
Class
Push button
Assembly arrangement
Modular device for domestic switching devices
Model
Single push button
Method of operation
Push button
Number of rockers
0
Number of modules (module system)
100
Number of poles
1
Nominal voltage
250 V
Rated current
10,00 A
Feedback-signal contact
No
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Anti-bacterial treatment
No
Surface protection
Lacquered
Surface finishing
Matt
Colour
Anthracite
RAL-number (similar)
7016
Transparent
No
Label space/information surface
Yes
Device width
22,30 mm
Device height
47,00 mm
Device depth
34,90 mm

00. CE Marking - EU

19. NOM - Mexico

29. QCERT - Colombia

29. QCERT - Colombia

37. Marking - Morocco

37. Marking - Morocco

99. WEEE Directive

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352666252
1 NR
6x2.8x5.3 [cm]
30.2 [g]
Barcode Qty 20 NR
8007352666269
20 NR
28.1x13.1x6 [cm]
690.8 [g]
Barcode Qty 240 NR
8007352666276
240 NR
38.5x28x30 [cm]
8,771.6 [g]
