Plate 5sp.M alum. snapfix gold - 08659

Pdf
Vimar - 08659 - Plate 5sp.M alum. snapfix gold
Vimar - 08659 - Plate 5sp.M alum. snapfix gold

08659
Wiring devices / Traditional wiring devices / 8000 / Cover plates

Plate 5sp.M alum. snapfix gold
5 special module cover plate for 5-module flush mounting boxes, anodized aluminium, snap fixing, gold. For mounting frame 08533.S

Product Status
3 - Active

Class group
Domestic switching devices
Class
Cover frame for domestic switching devices
Number of units
5
Mounting direction
Horizontal and vertical
Number of units horizontal
5
Number of units vertical
1
Number of modules horizontal (module system)
5
Number of modules vertical (module system)
1
With mounting grid
Yes
Suitable for subfloor installation duct box
Yes
Suitable for wall duct
Yes
Suitable for built-in installation
Yes
Label space/information surface
Yes
Material
Metal
Material quality
Aluminium
Halogen free
Yes
Surface protection
Anodised
Surface finishing
Matt
Colour
Aluminium
RAL-number (similar)
1035
Transparent
No
With hinged lid
No
Degree of protection (IP)
IP00
Type of fastening
Clamp mounting
Width
166,00 mm
Height
75,50 mm
Depth
6,00 mm
Built-in width
166,00 mm
Built-in height
75,50 mm
Diameter bore hole (opening)
0 mm
Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352032224
1 NR
16.6x7.5x0.6 [cm]
19.2 [g]
Barcode Qty 20 NR
8007352049109
20 NR
17.9x17x8.5 [cm]
462.33 [g]

Share

Codice QR scheda articolo

Legal

Vimar reserves the right to change at any time and without notice the characteristics of the products reported. Installation should be carried out by qualified staff in compliance with the current regulations regarding the installation of electrical equipment in the country where the products are installed. For the terms of use of the information on the product info sheet see Conditions of Use.
