1P 10AX 1-way switch +key - 08380

Pdf
Vimar - 08380 - 1P 10AX 1-way switch +key
Vimar - 08380 - 1P 10AX 1-way switch +key

08380
Wiring devices / Traditional wiring devices / 8000 / Devices

1P 10AX 1-way switch +key
1P 10 AX 250 V~ key-operated 1-way switch. Max 100 W for self-ballasted lamps (IEC 60669-1:2017)

Product Status
2 - Will be discontinued

Class group
Domestic switching devices
Class
Installation switch
Wiring system
Off switch 1-pole
Method of operation
Key
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
0
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Beige
RAL-number (similar)
9001
Label space/information surface
Yes
Illumination
No
Function lighting
Other
Type of lighting
Other
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 V
Rated current
10,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
Device height
45,00 mm
Device depth
43,00 mm
Built-in depth
33,50 mm

00. CE Marking - EU

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352014848
1 NR
6x2.8x5.3 [cm]
43.6 [g]
Barcode Qty 20 NR
8007352009363
20 NR
28.1x13.1x6 [cm]
953.87 [g]
