2P 15A USA+EU outlet for ø4,8mm plug - 08192

Pdf
Vimar - 08192 - 2P 15A USA+EU outlet for ø4,8mm plug
Vimar - 08192 - 2P 15A USA+EU outlet for ø4,8mm plug

08192
Wiring devices / Traditional wiring devices / 8000 / Devices

2P 15A USA+EU outlet for ø4,8mm plug
2P 15 A 250 V~ socket outlet, Euro-American standard (for plugs with parallel flat pins and ø 4,8 mm pins)

Product Status
3 - Active

Class group
Domestic switching devices
Class
Socket outlet
Model
Other
Number of units
1
Number of modules (module system)
1
Number of socket outlets switchable
0
Imprint/indication
None
Connection type
Screwed terminal
With hinged lid
No
With enhanced contact protection
No
Label space/information surface
Yes
Colour
White
RAL-number (similar)
9001
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
With function lighting
No
Over voltage protection
No
Fault current protection
No
Mounting method
Flush-mounted
Type of fastening
Snap mounting (engagement)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
With loop through function
No
With on/off switch
No
Rotated central insert
No
Nominal current
15 A
Nominal voltage
250 V
Frequency
50,00 - 60,00 HZ
Suitable for degree of protection (IP)
IP20
Impact strength
Other
Device height
45,00 mm
Device depth
32,50 mm

37. Marking - Morocco

Minimum order quantity: 50 NR

Barcode

Barcode Qty 1 NR
8007352014251
1 NR
4.1x2.8x5.3 [cm]
22.13 [g]
Barcode Qty 50 NR
8007352016521
50 NR
21.4x11.6x14.2 [cm]
1,190 [g]
