2P+E 16A P17/11 outlet - 08145

Pdf
Vimar - 08145 - 2P+E 16A P17/11 outlet
Vimar - 08145 - 2P+E 16A P17/11 outlet

08145
Wiring devices / Traditional wiring devices / 8000 / Devices

2P+E 16A P17/11 outlet
2P+E 16 A 250 V~ SICURY Bpresa socket outlet, Italian standard P17/11

Product Status
3 - Active

Drawings

view encumbered art. 08145
PNG DXF
rear view art. 08145
PNG DXF
3D view art. 08145
PNG DXF
Class group
Domestic switching devices
Class
Socket outlet
Model
Italian type Bipasso
Number of units
1
Number of modules (module system)
1
Number of socket outlets switchable
0
Imprint/indication
None
Connection type
Screwed terminal
With hinged lid
No
With enhanced contact protection
Yes
Label space/information surface
Yes
Colour
White
RAL-number (similar)
9001
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
With function lighting
No
Over voltage protection
No
Fault current protection
No
Mounting method
Flush-mounted
Type of fastening
Snap mounting (engagement)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
With loop through function
No
With on/off switch
No
Rotated central insert
No
Nominal current
16 A
Nominal voltage
250 V
Frequency
50,00 - 60,00 HZ
Suitable for degree of protection (IP)
IP20
Impact strength
Other
Device width
22,00 mm
Device height
50,10 mm
Device depth
32,50 mm

00. CE Marking - EU

07. INGCER - Chile

37. Marking - Morocco

99. WEEE Directive

Minimum order quantity: 50 NR

Barcode

Barcode Qty 1 NR
8007352014107
1 NR
4.1x2.8x5.3 [cm]
27.2 [g]
Barcode Qty 50 NR
8007352005082
50 NR
21.4x11.6x14.2 [cm]
1,448 [g]
Barcode Qty 500 NR
8007352263079
500 NR
57.5x22.5x30 [cm]
15,024 [g]
