2P 16AX 1-way switch luminous - 08039

Pdf
Vimar - 08039 - 2P 16AX 1-way switch luminous
Vimar - 08039 - 2P 16AX 1-way switch luminous

08039
Wiring devices / Traditional wiring devices / 8000 / Devices

2P 16AX 1-way switch luminous
2P 16 AX 250V~ 1-way switch, luminous, for signalling unit. Provided without signalling unit. Max 200 W for self-ballasted lamps (IEC 60669-1:2017)

Product Status
3 - Active

Class group
Domestic switching devices
Class
Installation switch
Wiring system
2-pole switch
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Beige
RAL-number (similar)
9001
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 V
Rated current
16,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
Yes
Device width
22,00 mm
Device height
50,10 mm
Device depth
42,00 mm
Built-in depth
30,50 mm

00. CE Marking - EU

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 50 NR

Barcode

Barcode Qty 1 NR
8007352078109
1 NR
5.1x2.8x5.3 [cm]
31.8 [g]
Barcode Qty 50 NR
8007352078116
50 NR
26.9x11.6x14.2 [cm]
1,689.07 [g]
