08037
Wiring devices / Traditional wiring devices / 8000 / Devices
1P 10AX 1-way switch luminous
1P 10 AX 250V~ 1-way switch, luminous, for signalling unit. Provided without signalling unit. Max 100 W for self-ballasted lamps (IEC 60669-1:2017)
Product Status
3 - Active
Class group
Domestic switching devices
Domestic switching devices
Class
Installation switch
Installation switch
Wiring system
Off switch 1-pole
Off switch 1-pole
Method of operation
Rocker/button
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Modular device for domestic switching devices
Number of modules (module system)
1
1
Push button switch
Yes
Yes
Number of rockers
1
1
Mounting method
Flush-mounted
Flush-mounted
Type of fastening
Engage (snap)
Engage (snap)
With mounting plate
No
No
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
Halogen free
Yes
Yes
Surface protection
Untreated
Untreated
Surface finishing
Matt
Matt
Colour
Beige
Beige
RAL-number (similar)
9001
9001
Label space/information surface
Yes
Yes
Illumination
Optional
Optional
Function lighting
Control and orientation
Control and orientation
Type of lighting
LED exchangeable
LED exchangeable
Suitable for degree of protection (IP)
IP40
IP40
Nominal voltage
250 V
250 V
Rated current
10,00 A
10,00 A
Feedback-signal contact
No
No
Connection type
Screwed terminal
Screwed terminal
Washing machine switch
No
No
Device width
22,00 mm
22,00 mm
Device height
50,10 mm
50,10 mm
Device depth
35,50 mm
35,50 mm
Built-in depth
24,00 mm
24,00 mm
Minimum order quantity: 20 NR
Barcode
8007352078062
1 NR
4.1x2.8x5.3 [cm]
24 [g]
8007352263741
20 NR
21.4x11.6x6 [cm]
541.13 [g]
8007352640177
200 NR
30.5x25.5x22.5 [cm]
5,740 [g]
