2P+E 16A German outlet ivory - 06417

Pdf
Vimar - 06417 - 2P+E 16A German outlet ivory
Vimar - 06417 - 2P+E 16A German outlet ivory

06417
Wiring devices / Traditional wiring devices / MASCOT / Devices

2P+E 16A German outlet ivory
2P+E 16 A 250 V~ socket outlet, German standard, thermosetting resin base, ivory

Product Status
2 - Will be discontinued

Class group
Domestic switching devices
Class
Socket outlet
Number of socket outlets switchable
0
Imprint/indication
None
Connection type
Screwed terminal
With hinged lid
No
With enhanced contact protection
No
Label space/information surface
Yes
Colour
White
RAL-number (similar)
9001
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
With function lighting
No
Over voltage protection
No
Fault current protection
No
Mounting method
Flush-mounted
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
With loop through function
No
With on/off switch
No
Rotated central insert
No
Nominal current
16 A
Nominal voltage
250 V
Frequency
50,00 - 60,00 HZ
Suitable for degree of protection (IP)
IP20
Impact strength
Other
Device width
80,00 mm
Device height
80,00 mm
Device depth
41,50 mm

00. CE Marking - EU

37. Marking - Morocco

99. WEEE Directive

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352039261
1 NR
8x8x3.6 [cm]
71.07 [g]
Barcode Qty 20 NR
8007352008809
20 NR
35.5x24.8x8.7 [cm]
1,656 [g]
