IoT connected multif.actuator 4out relay - 03985

Pdf
Vimar - 03985 - IoT connected multif.actuator 4out relay
Vimar - 03985 - IoT connected multif.actuator 4out relay

03985
Wiring devices / View Wireless wiring devices / Shared components / DIN devices

IoT connected multif.actuator 4out relay
VIEW Wireless electronic control actuator with 4 relay outputs 16 A 240 V~, programmable NO/NC with function to control lights, roller shutters with slat orientation, fan coil, climate control, accesses, sprinkler system, push buttons for local control, double IoT technology on Bluetooth 5.0 standard for the creation of VIEW Wireless mesh system, 100-240 V 50/60 Hz power supply, installation on DIN rail (60715 TH35), occupies 4 modules size 17.5 mm

Product Status
3 - Active

Class group
Installation bus systems
Class
Switch actuator for bus system
Bus system KNX
No
Bus system KNX-RF (Radio Frequency)
No
Bus system radio frequency
No
Bus system LON
No
Bus system Powernet
No
Other bus systems
None
Radio frequency bidirectional
Yes
Mounting method
Other
Width in number of modular spacings
4
Local operation/hand operation
Yes
With LED indication
Yes
Number of digital inputs
0
Suitable for C-load
Yes
Max. number of switching contacts
4
Max. switching current
16 A
Rated current
16 A
Different phases connectable
No
With bus connection
Yes
Bus module detachable
No
Modular expandability
No
Degree of protection (IP)
IP20

00. CE Marking - EU

01. IMQ - Italy

37. Marking - Morocco

99. WEEE Directive

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352767416
1 NR
11.7x10.8x7.1 [cm]
241.7 [g]
Barcode Qty 60 NR
8007352767423
60 NR
59x38.5x30 [cm]
15,225 [g]

Share

Codice QR scheda articolo

Legal

Vimar reserves the right to change at any time and without notice the characteristics of the products reported. Installation should be carried out by qualified staff in compliance with the current regulations regarding the installation of electrical equipment in the country where the products are installed. For the terms of use of the information on the product info sheet see Conditions of Use.
