8-input 8-output electronic board - 02096

Pdf

02096
Smart systems&products / Call-way / Surface mounting components / Non-modular components

8-input 8-output electronic board
8-input/8-output programmable control board 8 for the management of environments, for DIN (60715 TH35) rail installation, occupies 8 17,5 mm modules

Product Status
3 - Active

Sheets, Manuals, Documentation

Class group
Domestic switching devices
Class
Central-element clinic-installation
Suitable as central plate
No
Suitable for pull contact
No
Suitable for bus connection
Yes
Suitable for nurse call station
Yes
Colour
Other
RAL-number (similar)
6001

00. CE Marking - EU

37. Marking - Morocco

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352503816
1 NR
17.2x13x6 [cm]
256 [g]
Question: Are there any rules to comply with for the installation and programming of 8-channel MCS modules, article 02096?
Answer: Inputs and outputs are independently settable according to the required function but they must all be configured in the same ward.
Question: Can 8-channel MCS modules, article 02096, function in a system with no ADL EF (article 02094)?
Answer: Yes, after configuring and setting the MCS module (article 02096) it can function without the aid of an ADL EF.
