1-channel RF actuator/receiver - 01923

01923
Smart systems&products / Smart climate control / Shared components / DIN devices

1-channel RF actuator/receiver
1-channel radiofrequency actuator-receiver, for DIN (60715 TH35) rail installation, occupies 6 17,5 mm modules, RAL 7035 grey

Product Status
3 - Active

• Documents and downloads
• ETIM technical data
• Certifications
• Supply data
• Questions and answers

Sheets, Manuals, Documentation

• Installer manual (2073 kb)

Class group
Installation bus systems

Class
Heating actuator for bus system

Bus system KNX
No

Bus system KNX-RF (Radio Frequent)
No

Bus system radio frequent
Yes

Bus system LON
No

Bus system Powernet
No

Radio frequent bidirectional
No

Mounting method
Other

Width in number of modular spacings
6

With bus connection
No

Correcting variable consistent
No

Valve protection function
No

Manual switch
No

Max. switching current (resistive load)
16,00 A

Number of outputs
1

Max. output current
6,00 A

Switching voltage
250,00 - 250,01 V

Degree of protection (IP)
IP20

00. CE Marking - EU

00. CE Marking - EU

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 1 NR

---

Barcode

8007352153738

1 NR

11.7x10.8x7.1 [cm]

293.47 [g]

Question:	In case of low signal, can I improve the signal on unidirectional RF actuators 01923 and 01924?
Answer:	Yes, to improve reception, you can apply a rigid 17 cm wire to the relevant terminal or apply a 433Mhz antenna connected via coaxial cable.
Question:	Can a timer-thermostat 01910 with RF base 01930 manage an RF actuator 01923 or 01924?
Answer:	No, it can only manage two-way RF actuators 01933 or 01934.
Question:	Can I use the 01933 and 01934 two-way RF actuators in place of the 01923 or 01924 1-way RF actuators without using the 01930 2-way RF base?
Answer:	No, they have different operating frequencies and are conceptually different.
Question:	Can I control a single 01923 or 01924 RF actuator with multiple 01910 timer-thermostats?
Answer:	No.
Question:	Can I control multiple 01923 or 01924 RF actuators with an 01910 timer-thermostat?
Answer:	Yes.
Question:	Is an antenna required on the 01923-01924 RF actuator/receiver?
Answer:	Yes, otherwise the RF coverage would not be satisfactory.
Question:	What is the coverage between timer-thermostat and an 01923-01924 RF actuator/receiver?
Answer:	120 meters in the open. To increase the range you can use an additional actuator acting as a ˝repeater˝.

---
