SLAVE dimmer 230V 1000W/VA - 01862

Pdf
Vimar - 01862 - SLAVE dimmer 230V 1000W/VA
Vimar - 01862 - SLAVE dimmer 230V 1000W/VA

01862
Smart systems&products / By-me Plus / Shared components / DIN devices

SLAVE dimmer 230V 1000W/VA
SLAVE dimmer, 230 V~ 50/60 Hz for: 40-1000 W incandescent lamps, 40-1000 VA ferromagnetic transformers, from 01861 control, protection fuse, MOSFET+TRIAC technology, for DIN (60715 TH35) rail installation, occupies 4 17,5 mm modules

Product Status
2 - Will be discontinued

Sheets, Manuals, Documentation

Drawings

view encumbered art. 01862
PNG DXF
rear view art. 01862
PNG DXF
3D view art. 01862
PNG DXF
Class group
Installation bus systems
Class
Dimming actuator for bus system
Bus system KNX
No
Bus system KNX-RF (Radio Frequent)
No
Bus system radio frequent
No
Bus system LON
No
Bus system Powernet
No
Other bus systems
Other
Radio frequent bidirectional
No
Model
Dimming actuator
Mounting method
Other
Width in number of modular spacings
4
With bus connection
No
Bus module detachable
No
Local operation/hand operation
No
With LED indication
Yes
Number of outputs
1
Output power
40 - 1.000 W
Power boost suitable
Yes
Type of load
Universal
Voltage
230,00 - 230,01 V
Parallel-service possible
No
Frequency
50,00 - 60,00 HZ
Degree of protection (IP)
IP20

00. CE Marking - EU

99. WEEE Directive

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352387430
1 NR
11.7x10.8x7.1 [cm]
200.6 [g]
