MASTER dimmer 230V 1000W/VA - 01861

Pdf
Vimar - 01861 - MASTER dimmer 230V 1000W/VA
Vimar - 01861 - MASTER dimmer 230V 1000W/VA

01861
Smart systems&products / By-me Plus / Shared components / DIN devices

MASTER dimmer 230V 1000W/VA
Dimmer, 230 V~ 50/60 Hz for: 40-1000 W incandescent lamps, 40-1000 VA ferromagnetic transformers, MASTER function for 01862, protection fuse, MOSFET+TRIAC technology, for DIN (60715 TH35) rail installation, occupies 4 17,5 mm modules

Product Status
2 - Will be discontinued

Sheets, Manuals, Documentation

Drawings

view encumbered art. 01861
PNG DXF
rear view art. 01861
PNG DXF
3D view art. 01861
PNG DXF
Class group
Installation bus systems
Class
Dimming actuator for bus system
Bus system KNX
No
Bus system KNX-RF (Radio Frequent)
No
Bus system radio frequent
No
Bus system LON
No
Bus system Powernet
No
Other bus systems
Other
Radio frequent bidirectional
No
Model
Dimming actuator
Mounting method
Other
Width in number of modular spacings
4
With bus connection
Yes
Bus module detachable
No
Local operation/hand operation
No
With LED indication
Yes
Number of outputs
1
Output power
40 - 1.000 W
Power boost suitable
No
Type of load
Universal
Voltage
230,00 - 230,01 V
Parallel-service possible
No
Frequency
50,00 - 60,00 HZ
Degree of protection (IP)
IP20

00. CE Marking - EU

99. WEEE Directive

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352387423
1 NR
11.7x10.8x7.1 [cm]
206.4 [g]
