By-alarm Plus DT IP54 curtain surf.det. - 01723

Pdf
Vimar - 01723 - By-alarm Plus DT IP54 curtain surf.det.
Vimar - 01723 - By-alarm Plus DT IP54 curtain surf.det.

01723
Safety / By-alarm Plus / Surface mounting components / Non-modular components

By-alarm Plus DT IP54 curtain surf.det.
By-alarm Plus IP54 dual technology curtain-effect detector to protect entrances and openings such as doors, windows, covered terraces, corridors and French doors, anti-masking function, SET input to disable microwaves when system not on, surface mounting for outdoor use

Product Status
3 - Active

Sheets, Manuals, Documentation

Drawings

view encumbered art. 01723
PNG DXF
rear view art. 01723
PNG DXF
3D view art. 01723
PNG DXF
Class group
Alarm installations, emergency call and signalling
Class
Movement detector for danger detection system
Type of messaging
Infrared/microwave (Dual)
Mounting method
Surface mounting
Operating current
70,00 mA
Operating voltage
12,00 - 12,01 V
Height
155,70 mm
Width
71,50 mm
Depth
103,00 mm
Characteristic
Curtain
Cover monitoring
Yes
Radio system
No

00. CE Marking - EU

00. CE Marking - EU

37. Marking - Morocco

46. UK PSTI compliance

99. WEEE Directive

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352548107
1 NR
15.9x11.4x8.9 [cm]
347 [g]
Barcode Qty 50 NR
8007352575356
50 NR
80x40x22 [cm]
18,384 [g]
