01560.B
Smart systems&products / KNX / Shared components / Devices
KNX 5in touch screen white
˝5˝˝ colour touch screen for control and home automation system control, KNX standard, complete with mounting frame for installation in 2-3 module boxes, white˝
Product Status
3 - Active
Sheets, Manuals, Documentation
- Light multilanguage instructions sheet (1047 kb)
- Foglio istruzioni Full (683 kb)
- Feuille d’instructions Full (683 kb)
- Hoja de instrucciones Full (682 kb)
- Full instructions sheet (681 kb)
- Φυλλάδιο οδηγιών Full (798 kb)
- Anweisungsblatt Full (682 kb)
- ورقة الإرشادات Full (716 kb)
- Manuale installatore (7365 kb)
- Installer manual (22846 kb)
- Manuale utente (5688 kb)
- User manual (5673 kb)
Product Software
Drawings
Class group
Installation bus systems
Installation bus systems
Class
Signalling and operation panel for bus system
Signalling and operation panel for bus system
Bus system KNX
Yes
Yes
Bus system KNX-RF (Radio Frequency)
No
No
Bus system radio frequency
No
No
Bus system LON
No
No
Bus system Powernet
No
No
Other bus systems
None
None
Radio frequency bidirectional
No
No
Assembly arrangement
Control element
Control element
Model
Signalling and operating panel
Signalling and operating panel
Mounting method
Surface mounted
Surface mounted
Display
Colour
Colour
Touch function
Yes
Yes
With bus connection
Yes
Yes
Material
Plastic
Plastic
Material quality
Other
Other
Colour
White
White
RAL-number (similar)
9016
9016
Degree of protection (IP)
IP20
IP20
Minimum order quantity: 1 NR
Barcode
8007352755802
1 NR
18.8x10.2x5.7 [cm]
367 [g]
