Solenoid valve actuator 6 out 230V KNX - 01535

01535
Smart systems&products / KNX / Shared components / DIN devices

Solenoid valve actuator 6 out 230V KNX
Actuator for solenoid valves, 6 (six) 230 V~ 0.5 A outputs, push buttons for local control, KNX standard, installation on DIN rail (60715 TH35), occupies 4 modules size 17.5 mm

Product Status
3 - Active

• Documents and downloads
• ETIM technical data
• Certifications
• Supply data

Sheets, Manuals, Documentation

• Multilanguage instructions sheet (521 kb)
• Manuale installatore (3946 kb)
• Installer manual (3274 kb)

Product Software

• DB_ComponentiAutomazione_KNX_01.16_20210920.zip
• DB_ComponentiAutomazione_KNX_01.19_20230331.zip
• DB_ComponentiAutomazione_KNX_01.20_20240917.zip

---

Drawings

PNG DXF

PNG DXF

PNG DXF

Class group
Installation bus systems

Class
Heating actuator for bus system

Bus system KNX
Yes

Bus system KNX-RF (Radio Frequent)
No

Bus system radio frequent
No

Bus system LON
No

Bus system Powernet
No

Radio frequent bidirectional
No

Mounting method
Other

Width in number of modular spacings
4

With bus connection
Yes

Correcting variable consistent
No

Valve protection function
Yes

Manual switch
Yes

Max. switching current (resistive load)
0,50 A

Number of outputs
6

Max. output current
0,75 A

Switching voltage
24,00 - 230,00 V

Degree of protection (IP)
IP20

00. CE Marking - EU

27. KNX

37. Marking - Morocco

46. UK PSTI compliance

99. WEEE Directive

Minimum order quantity: 1 NR

---

Barcode

8007352561434

1 NR

9.3x7.8x6.5 [cm]

169.5 [g]

8007352762206

11 NR

40x37x8 [cm]

2,062.5 [g]
